Code Execution for Parsing, Analyzing, Visualizing, and Debugging Agent Reasoning Traces using the lambda/hermes-agent-reasoning-traces dataset

!pip -q install -U datasets pandas matplotlib seaborn transformers accelerate trl


import json, re, random, textwrap
from collections import Counter, defaultdict
import pandas as pd
import numpy as np
import matplotlib.pyplot as plt
from datasets import load_dataset, concatenate_datasets


random.seed(0)


CONFIG = "kimi"
ds = load_dataset("lambda/hermes-agent-reasoning-traces", CONFIG, split="train")
print(ds)
print("Config:", CONFIG, "| Fields:", ds.column_names)
print("Categories:", sorted(set(ds["category"])))


COMPARE_BOTH = False
if COMPARE_BOTH:
   ds_kimi = load_dataset("lambda/hermes-agent-reasoning-traces", "kimi", split="train")
   ds_glm  = load_dataset("lambda/hermes-agent-reasoning-traces", "glm-5.1", split="train")
   ds_kimi = ds_kimi.add_column("source", ["kimi"] * len(ds_kimi))
   ds_glm  = ds_glm.add_column("source", ["glm-5.1"] * len(ds_glm))
   ds = concatenate_datasets([ds_kimi, ds_glm]).shuffle(seed=0)
   print("Combined:", ds, "→ counts:", Counter(ds["source"]))


sample = ds[0]
print("n=== Sample 0 ===")
print("id        :", sample["id"])
print("category  :", sample["category"], "/", sample["subcategory"])
print("task      :", sample["task"])
print("turns     :", len(sample["conversations"]))
print("system[0] :", sample["conversations"][0]["value"][:220], "...n")

THINK_RE     = re.compile(r"<think>(.*?)</think>", re.DOTALL)
TOOL_CALL_RE = re.compile(r"<tool_call>s*({.*?})s*</tool_call>", re.DOTALL)
TOOL_RESP_RE = re.compile(r"<tool_response>s*(.*?)s*</tool_response>", re.DOTALL)


def parse_assistant(value: str) -> dict:
   thoughts = [t.strip() for t in THINK_RE.findall(value)]
   calls = []
   for raw in TOOL_CALL_RE.findall(value):
       try:
           calls.append(json.loads(raw))
       except json.JSONDecodeError:
           calls.append({"name": "<malformed>", "arguments": {}})
   final = TOOL_CALL_RE.sub("", THINK_RE.sub("", value)).strip()
   return {"thoughts": thoughts, "tool_calls": calls, "final": final}


def parse_tool(value: str):
   raw = TOOL_RESP_RE.search(value)
   if not raw: return {"raw": value}
   body = raw.group(1)
   try:    return json.loads(body)
   except: return {"raw": body}


first_gpt = next(t for t in sample["conversations"] if t["from"] == "gpt")
p = parse_assistant(first_gpt["value"])
print("Thought preview :", (p["thoughts"][0][:160] + "...") if p["thoughts"] else "(none)")
print("Tool calls       :", [(c.get("name"), list(c.get("arguments", {}).keys())) for c in p["tool_calls"]])

N = 3000
sub = ds.select(range(min(N, len(ds))))


tool_calls         = Counter()
parallel_widths    = Counter()
thoughts_per_turn  = []
calls_per_traj     = []
errors_per_traj    = []
turns_per_traj     = []
cat_counts         = Counter()


for ex in sub:
   cat_counts[ex["category"]] += 1
   n_calls = n_err = 0
   turns_per_traj.append(len(ex["conversations"]))
   for t in ex["conversations"]:
       if t["from"] == "gpt":
           p = parse_assistant(t["value"])
           thoughts_per_turn.append(len(p["thoughts"]))
           if p["tool_calls"]:
               parallel_widths[len(p["tool_calls"])] += 1
               for c in p["tool_calls"]:
                   tool_calls[c.get("name", "<unknown>")] += 1
               n_calls += len(p["tool_calls"])
       elif t["from"] == "tool":
           r = parse_tool(t["value"])
           blob = json.dumps(r).lower()
           if "error" in blob or '"exit_code": 1' in blob or "traceback" in blob:
               n_err += 1
   calls_per_traj.append(n_calls)
   errors_per_traj.append(n_err)


print(f"nScanned {len(sub)} trajectories")
print(f"Avg turns/traj      : {np.mean(turns_per_traj):.1f}")
print(f"Avg tool calls/traj : {np.mean(calls_per_traj):.1f}")
print(f"% with >=1 error    : {100*np.mean([e>0 for e in errors_per_traj]):.1f}%")
print(f"% parallel turns    : {100*sum(v for k,v in parallel_widths.items() if k>1)/max(1,sum(parallel_widths.values())):.1f}%")
print("Top 10 tools        :", tool_calls.most_common(10))


fig, axes = plt.subplots(2, 2, figsize=(13, 9))


top = tool_calls.most_common(15)
axes[0,0].barh([t for t,_ in top][::-1], [c for _,c in top][::-1], color="teal")
axes[0,0].set_title("Top 15 tools by call volume")
axes[0,0].set_xlabel("calls")


ks = sorted(parallel_widths)
axes[0,1].bar([str(k) for k in ks], [parallel_widths[k] for k in ks], color="coral")
axes[0,1].set_title("Tool-calls per assistant turn (parallel width)")
axes[0,1].set_xlabel("# tool calls in one turn"); axes[0,1].set_ylabel("count")
axes[0,1].set_yscale("log")


axes[1,0].hist(turns_per_traj, bins=40, color="steelblue")
axes[1,0].set_title("Conversation length"); axes[1,0].set_xlabel("turns")


cats, vals = zip(*cat_counts.most_common())
axes[1,1].pie(vals, labels=cats, autopct="%1.0f%%", startangle=90)
axes[1,1].set_title("Category distribution")


plt.tight_layout(); plt.show()

def render_trace(ex, max_chars=350):
   print(f"n{'='*72}nTASK [{ex['category']} / {ex['subcategory']}]: {ex['task']}n{'='*72}")
   for t in ex["conversations"]:
       role = t["from"]
       if role == "system":
           continue
       if role == "human":
           print(f"n[USER]n{textwrap.shorten(t['value'], 600)}")
       elif role == "gpt":
           p = parse_assistant(t["value"])
           for th in p["thoughts"]:
               print(f"n[THINK]n{textwrap.shorten(th, max_chars)}")
           for c in p["tool_calls"]:
               args = json.dumps(c.get("arguments", {}))[:200]
               print(f"[CALL] {c.get('name')}({args})")
           if p["final"]:
               print(f"n[ANSWER]n{textwrap.shorten(p['final'], max_chars)}")
       elif role == "tool":
           print(f"[TOOL_RESPONSE] {textwrap.shorten(t['value'], 220)}")
   print("="*72)


idx = int(np.argmin(np.abs(np.array(turns_per_traj) - 10)))
render_trace(sub[idx])


def get_tool_schemas(ex):
   try:    return json.loads(ex["tools"])
   except: return []


schemas = get_tool_schemas(sample)
print(f"nSample 0 has {len(schemas)} tools available")
for s in schemas[:3]:
   fn = s.get("function", {})
   print(" -", fn.get("name"), "—", (fn.get("description") or "")[:80])


ROLE_MAP = {"system": "system", "human": "user", "gpt": "assistant", "tool": "tool"}


def to_openai_messages(conv):
   return [{"role": ROLE_MAP[t["from"]], "content": t["value"]} for t in conv]


example_msgs = to_openai_messages(sample["conversations"])
print("nFirst 2 OpenAI messages:")
for m in example_msgs[:2]:
   print(" ", m["role"], "→", m["content"][:120].replace("n", " "), "...")

from transformers import AutoTokenizer
TOK_ID = "Qwen/Qwen2.5-0.5B-Instruct"
tok = AutoTokenizer.from_pretrained(TOK_ID)


def build_masked(conv, tokenizer, max_len=2048):
   msgs = to_openai_messages(conv)
   for m in msgs:
       if m["role"] == "tool":
           m["role"] = "user"
           m["content"] = "[TOOL OUTPUT]n" + m["content"]
   input_ids, labels = [], []
   for m in msgs:
       text = tokenizer.apply_chat_template([m], tokenize=False, add_generation_prompt=False)
       ids = tokenizer.encode(text, add_special_tokens=False)
       input_ids.extend(ids)
       labels.extend(ids if m["role"] == "assistant" else [-100] * len(ids))
   return input_ids[:max_len], labels[:max_len]


ids, lbls = build_masked(sample["conversations"], tok)
trainable = sum(1 for x in lbls if x != -100)
print(f"nTokenized example: {len(ids)} tokens, {trainable} trainable ({100*trainable/len(ids):.1f}%)")


think_lens, call_lens, ans_lens = [], [], []
for ex in sub.select(range(min(500, len(sub)))):
   for t in ex["conversations"]:
       if t["from"] != "gpt": continue
       p = parse_assistant(t["value"])
       for th in p["thoughts"]: think_lens.append(len(th))
       for c in p["tool_calls"]: call_lens.append(len(json.dumps(c)))
       if p["final"]: ans_lens.append(len(p["final"]))


plt.figure(figsize=(10,4))
plt.hist([think_lens, call_lens, ans_lens], bins=40, log=True,
        label=["<think>", "<tool_call>", "final answer"], stacked=False)
plt.legend(); plt.xlabel("characters"); plt.title("Length distributions (log y)")
plt.tight_layout(); plt.show()


class TraceReplayer:
   def __init__(self, ex):
       self.ex = ex
       self.steps = []
       pending = None
       for t in ex["conversations"]:
           if t["from"] == "gpt":
               if pending: self.steps.append(pending)
               pending = {"think": parse_assistant(t["value"]), "responses": []}
           elif t["from"] == "tool" and pending:
               pending["responses"].append(parse_tool(t["value"]))
       if pending: self.steps.append(pending)
   def __len__(self): return len(self.steps)
   def play(self, i):
       s = self.steps[i]
       print(f"n── Step {i+1}/{len(self)} ──")
       for th in s["think"]["thoughts"]:
           print(f" {textwrap.shorten(th, 280)}")
       for c in s["think"]["tool_calls"]:
           print(f"  {c.get('igama')}({json.dumps(c.get('arguments', {}))[:140]})") kwe-r ku-s["responses"]: phrinta (f" {textwrap.shorten(json.dumps(r), 200)}") if sec["think"]["final"]: print (f" {text.shorten['think']['final']200)}") rp = TraceReplayer(sample) for i in range(min(3, len(rp))): rp.play(i) TRAIN = False if TRAIN: import torch from transformers import AutoModelForCausalLM from trl import SFTTrainer, SFTConfig train_select0(range train_subset)(range train_subset) to_text(bundle): msgs = to_openai_messages(bundle["conversations"]) in m messages: if m["role"] == "tool": m["role"] = "user"; m["content"] = "[TOOL]n" + m["content"]
       collection["text"] = tok.apply_chat_template(msgs, tokenize=False, add_generation_prompt=False) return bundle train_subset = train_subset.map(to_text) model = AutoModelForCausalLM.from_pretrained(TOK_ID, torch_dtype=torch.float16.itorch.il2) device_map="default" if torch.cuda.is_available() else ) cfg = None SFTConfig( output_dir="hermes-sft-demo", per_device_train_batch_size=1, gradient_accumulation_steps=4, max_steps=20, learning_rate,2_step-2e max_seq_length=1024, dataset_text_field="text", report_to="none", fp16=torch.cuda.is_available(), ) SFTTrainer(model=model, args=cfg, train_dataset=train_subset, processing_class=tok).train() print("completed) print ok." The tutorial is complete. You now have analyzers, statistics, plots, a player and, " "SFT examples with the token + hidden label, and an optional training hook.")
